    1500LB ASME B16.36 F304 Stainless Steel Blind Flange

    Ask Lasest Price
    Brand Name : zexu
    Model Number : CL150-CL300
    Certification : CE API ISO9001
    Price : 12-2700USD
    Payment Terms : T/T
    Supply Ability : 30000ton/Year
    Delivery Time : 5work days
    • Product Details
    • Company Profile

    1500LB ASME B16.36 F304 Stainless Steel Blind Flange

    ASME B16.36 F304 Stainless Steel Blind Flange For Sealing Pipes

    A Blind Flange has no bore, and is used to close ends of piping systems. A blind flange also permits easy access to a line ones it has been sealed. The blind flange is sometimes machined to accept a pipe of the nominal Size to which reduction is being made. The reduction can be either threaded or welded.

    ProductStainless steel Blind Flange
    Material GradeF304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L, Duplex stainless steel UNS S31803, 2205, Super Duplex stainless steel UNS S32750
    CertificationISO9001:2015, TS
    StandardANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48

    DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673

    B.S : BS4504 , BS4504, BS1560, BS10
    Size10-2000
    Pressure150#, 300#,400 #,600#,900#, 1500# & 2500 #.
    TypeBL
    Flange surfaceFF, RF,MFM,TG,RJ
    Stainless SteelASTM A182 F304,F304L,F316,F316L,1cr18Ni9Ti,0cr18Ni9Ti,321,18-8

    The date as follow:

    150#
    Branch NBADEFGx.No.Weight kg
    1/2" (15)8911,635.060.315.8 x 40.6
    3/4" (20)9913.243.069.815.8 x 40.8
    1" (25)10814.751.079.415.8 x 41.1
    1 1/2" (40)12719.573.098.415.8 x 41.8
    2" (50)15222.792.0120.619.0 x 42.7
    3" (80)19124.3127.0152.419.0 x 44.5
    4" (100)22924.3157.0190.519.0 x 47.0
    6" (150)27925.9215.0241.322.2 x 810.8
    8" (200)34329.0270.0298.422.2 x 818.0
    10" (250)40030.6324.0362.025.4 x 1224.0
    12" (483)48332.2381.043225.4 x 1237.0
    14" (350)53335.4413.0476.328.4 x 1214.0
    16" (400)59737.0470.0539.828.4 x 1261.0
    18" (450)63540.1533.0577.931.8 x 1668.0
    20" (500)69843.3584.0635.031.8 x 1684.0
    24" (600)81347.8692.0749.335.0 x 16115.0

    .

    300#
    Branch NBADEFGx.No.Weight kg
    1/2" (15)9614.735.060.715.8 x 41.5
    3/4" (20)11716.343.082.619.8 x 41.8
    1" (25)12417.951.088.919.8 x 42.0
    1 1/2" (40)15621.173.0114.322.2 x 43.5
    2" (50)16522.792.0127.019.0 x 84.0
    3" (80)21029.0127.0168.322.2 x 87.0
    4" (100)25432.2157.0200.022.2 x 811.0
    6" (150)31837.0215.0269.922.2 x 1219.0
    8" (200)38141.7270.0330.225.4 x 1230.0
    10" (250)44548.1324.0387.428,5 x 1641.0
    12" (483)52151.3381.0450.831.8 x 1662.0
    14" (350)58454.4413.0514.331.8 x 2086.0
    16" (400)64857.6470.0571.535.0 x 20106.0
    18" (450)71160.8533.0628.635.0 x 24131.0
    20" (500)77564.0584.0685.835.0 x 24158.0
    24" (600)91470.3692.0812.841.0 x 24230.0
